OIL IMMERSED TRANSFORMER HERMETICALLY SEAL TYPE

100 kVA 3Phase 50Hz 22000 - 416/240V.


LENGTH  (L) = 1000 mm.
WIDTH (W) = 650 mm.
HEIGHT (H) = 1200 mm.
TOTAL WEIGHT = 650 Kg.
OIL VOLUME = 160 Litre
POWER RATED = 100 Kva
NO LOAD LOSSES = 180 Watt
LOAD LOSSES AT 75°C
= 1450 Watt
IMPEDANCE AT 75°C
= 4.00 & ±10 %
EFFICIENCY (P.F.=1) 1/2 Load
= 98.93 %
EFFICIENCY (P.F.=1) full Load
= 98.40 %
VOLTAGE REGULATION AT FULLLOAD (P.F.=1)(%) = 1.51 %
NOISE LEVEL = ≤ 51 dB (A)
